Key Features
-
"LM Series FireHawk" Split Shaft PTO inline power take off are perfectly designed to transmit power & torque upto 160 HP vehicles.
-
Single Casing with Spur Gears for Smooth Operations
-
Installed in midship position between the truck transmission and & the rear axle.
-
Excellent Interchangeability and Easy Serviceability
-
Stronger Built With Oil Lubricated oversized bearing
-
Avalibility of Flanges as per vehicle Weight - 70 kg
-
High Quality Double lip oil Seals with Inbuilt water cooling systems
-
Additional provision of PTO Mounting Pads For Excellant vibration damping
-
Available Ratios - 1:1.33 & 1:1.48 *Other ratios can also be made available on request.
Key Features
-
"FM Series FireHawk" split shaft inline power take off are perfectly designed to transmit power & torque upto 300 HP vehicles.
-
Single Casing with Helical Gears for Smooth Operations
-
Installed in midship position between the truck transmission and & the rear axle.
-
Excellent Interchangeability and Easy Serviceability
-
Stronger Built With Oil Lubricated oversized bearing
-
Avalibility of Flanges as per vehicle Weight - 92.5 kg
-
High Quality Double lip oil Seals with Inbuilt water cooling systems
-
Additional provision of PTO Mounting Pads For Excellant vibration damping
-
Available in four different ratios (1:1.17, 1:1.31, 1:1.48, 1:1.62)
-
*Other ratios can also be made available on request.
